BB435

Powerful, Rugged & Smart Energy Solution for High-Drain Equipment

The BLUESHAPE BB435 is a top-tier 435Wh B-Mount battery, designed for high-power cinema cameras, broadcast equipment, and mission-critical applications. Built with the advanced 21700 Li-Ion cell format, this battery optimizes efficiency, minimizes internal impedance, and ensures maximum performance for high-drain devices.

With its massive capacity, extended runtime, and robust build, the BB435 is the ideal choice for professionals who need reliable power on set. Featuring GRANITE shockproof construction and an IP54 rainproof rating, this battery is built to endure demanding environments.

Equipped with USB-C PD for fast charging, LED touch control, and Wi-Fi-enabled GRANITE SMART connectivity, the BB435 offers real-time battery monitoring and seamless power management via the GRANITE SMART app.

Key Features:

435Wh Ultra High-Capacity Power – Maximum runtime for high-drain cameras & equipment.
B-Mount Standard – Ensures seamless compatibility with industry-leading devices.
21700 Li-Ion Cell Format – Enhanced efficiency & reduced internal impedance for power-hungry applications.
GRANITE Shockproof & IP54 Weatherproof – Designed to handle extreme production environments.
USB-C PD Power Source & Data Outlet – Fast charging & flexible connectivity.
Wi-Fi-Enabled GRANITE SMART Monitoring – Real-time tracking & power management via the app.
LED Touch Control – Quickly check charge status & activate functions with ease.
IATA Travel Restrictions Apply – Must be transported as cargo under IATA regulations.

Why Choose the BLUESHAPE BB435?

The BB435 is the ultimate high-capacity B-Mount battery, engineered for cinematographers, broadcasters, and professionals who require extended runtime and uninterrupted power. Whether filming in demanding locations or powering energy-intensive setups, this rugged, intelligent battery ensures your production runs smoothly.

Upgrade your power solution with the BLUESHAPE BB435 – Order today!

• Dimensions: 155mm x 105mm x 94mm (6.1" x 4.14" x 3.7")
• Weight: 2.2 Kgs (4.85lbs)
• Nominal Voltage: 28.8V (voltage range: 21.0V ~ 33.6V)
• Nominal capacity: 15Ah - 435Wh
• Max current draw: 20A
• Solid and robust shockproof and rainproof construction IP54 certified
• Two 5x RGB LED array located in the corner of the housing to guarantee maximum visibility at 270 degrees around the battery, even if the battery is installed upside down on a stabilizer or other devices.
• The LEDs are activated by touch-sensitive switches that allow for several unique functions such as setting the LEDs to always on for an immediate and remote glance at the battery charge status during use, or varying the intensity of the LEDs according to the needs of the shooting environment.
• The battery is further enhanced with more power options:
  • 2x 16V D-Tap for a combined max output of 80W
  • 1x USBC-PD 5V~20V up to 65W useful to power an array of devices

• The USB-C output is also equipped for the useful and unique personal SMARTMon function that provides each user with the ability to interface with their battery via a simple USB-C data cable to monitor and control its functions in direct connection with our customer service
• The new GRANITE SMART wireless connectivity boosts the usage in the field: compatible with most smartphone and tablets, connects immediately out of the box and helps to control all the batteries in real time during use without lengthy pairing operations
• The new B-mount range is ready for use with the optional BSAFE, a market first metal bracket that secures the battery to the safety cable system when used on overhead equipment.

• 1x BB435
• 1x Charging Cable
• 1x User Guide & Quick Start Manual

GRANITE SMART B-Mount battery series operator manual (web version)

Technical information of BLUESHAPE B-MOUNT batteries
