The High End Systems HPU (Hybrid Processor Unit) is a versatile powerhouse within the Hog 4 family, capable of functioning as both a rack-mounted console and a DMX processor. Designed to output up to 64 universes, this compact 2U 19-inch rack-mounted unit is a must-have for large-scale lighting installations, cruise ships, theme parks, and architectural applications.
Key Features:
64 Universes of Output – Delivers 32,768 parameters in both console and processor modes, expandable via DMX processors (DP8K or additional HPUs).
Rack-Mountable & Space-Saving – Optimized for permanent installations where a physical front-panel interface is not required.
Powerful Control System – Hog 4 OS, built-in 8” color multitouch display, and support for two DisplayPort monitors/touchscreens.
Flexible Configuration – Connect a Hoglet 4, add touchscreen monitors, and transform into a complete console.
Network Ready – Dual Ethernet ports for HogNet and FixtureNet, ensuring reliable sACN and Art-Net integration.
Robust DMX Capabilities – Includes 8 Neutrik XLR-5 DMX outputs, OSC I/O, and USB expansion ports for wings, widgets, and peripherals.
Advanced Programming & Playback – Supports cue level timing, pixel mapping effects, virtual masters, OSC input/output, MIDI control, and more.
Scalable & Redundant System – Functions as a backup console for any Hog 4 family console, ensuring fail-safe operations.
Rugged & Reliable – Solid-state drive, ETL and CE compliant, with a universal 100–250 VAC power supply.
Designed for Maximum Flexibility
In Console Mode, the HPU serves as a compact yet full-featured Hog 4 console. In Processor Mode, it extends the output capacity of any Hog 4 console, delivering up to 64 universes per unit. For larger installations, multiple HPUs can be combined to scale up output capacity.
From broadcast studios to live concerts, the High End Systems HPU ensures unparalleled control, scalability, and efficiency for your lighting productions.
